Product Introduction Of The ALUMINUM BUBBLE FOIL
Experience double the protection! Our enhanced double-layer bubble foil configuration provides maximum thermal resistance for harsh environments. The dual bubble layers create additional air pockets that dramatically reduce heat conduction, making it ideal for industrial facilities, agricultural buildings, and extreme climate zones. With improved tensile strength (34/26 Mpa) and zero linear shrinkage, this robust solution maintains performance under demanding conditions.
Product Characterics Of The ALUMINUM BUBBLE FOIL
-
Double bubble layer design
-
Enhanced thermal resistance
-
Superior tensile strength
-
No shrinkage or corrosion
-
Mold and mildew resistant
Product Parameter Of The ALUMINUM BUBBLE FOIL—Fire retardant Aluminum / Bubble / Aluminum
|
Aluminum + Bubble + Aluminum
|
|
ITEM
|
UNIT
|
VALUE
|
|
Aluminum thick
|
micron
|
7
|
|
Bubble size (Diameter*Height)
|
mm
|
10*4
|
|
Bubble weight
|
kg/m²
|
0.26
|
|
Emissivity
|
COEF
|
0.03 ~ 0.04
|
|
Reflectivity
|
%
|
95~97
|
|
Water vapor transmission
|
G/m²KPA
|
0.012
|
|
Service temperature range
|
℃
|
-40 ~ + 80
|
|
Tensile Strength (MD / TD)
|
Mpa
|
34 / 26
|
|
Linear Shrinkage
|
-----
|
None
|
|
Corrosion
|
-----
|
None
|
|
Pliability
|
-----
|
No cracking
|
|
Mold and mildew
|
-----
|
No growth
|
|
Fire rating
|
-----
|
Class A / Class 1
|
OTHERS:
Max width: 1.50m
Length: according to customer request
Bubble diameter: 6mm, 10mm, 12mm, 20mm, 25mm
Product Parameter Of The ALUMINUM BUBBLE FOIL—Fire retardant Aluminum / Double- layer bubble / Aluminum
|
Aluminum + Bubble Bubble + Aluminum
|
|
ITEM
|
VALUE
|
|
Aluminum thick
|
7 micron
|
|
Bubble size
|
10mm * 7mm ( Diameter * Height)
|
|
Bubble weight
|
0.3kg/m²
|
|
Emissivity
|
0.03 ~ 0.04 COEF
|
|
Reflectivity
|
95~97 %
|
|
Water vapor transmission
|
0.012 G/m²KPA
|
|
Service temperature range
|
-40 ~ + 80 ℃
|
|
Tensile Strength (MD / TD)
|
34 / 26
|
|
Linear Shrinkage
|
None
|
|
Corrosion
|
None
|
|
Pliability
|
No cracking
|
|
Mold and mildew
|
No growth
|
|
Fire rating
|
Class A / Class 1
|
OTHERS:
Max width: 1.50m
Length: according to customer request
Bubble diameter: 6mm, 10mm, 12mm, 20mm, 25mm
Product Introduction Of The ALUMINUM BUBBLE FOIL—Fire retardant Aluminum foil / Woven Cloth / Bubble / Woven Cloth / Aluminum
This material is added PE woven cloth between the aluminum foil and bubble foil, it can hence the tensile strength and tear resistance, can be stable-working in roofing and wall system.
Product Parameter Of The ALUMINUM BUBBLE FOIL—Fire retardant Aluminum foil / Woven Cloth / Bubble / Woven Cloth / Aluminum
|
Aluminum foil / Woven Cloth / Bubble / Woven Cloth / Aluminum
|
|
ITEM
|
VALUE
|
|
Aluminum thick
|
7 micron
|
|
Bubble size
|
10mm * 7mm ( Diameter * Height)
|
|
Bubble weight
|
0.3 kg/m²
|
|
Emissivity
|
0.03 ~ 0.04 COEF
|
|
Reflectivity
|
95~97 %
|
|
Water vapor transmission
|
0.012 G/m²KPA
|
|
Service temperature range
|
-40 ~ + 80 ℃
|
|
Tensile Strength (MD / TD)
|
34 / 26 Mpa
|
|
Linear Shrinkage
|
None
|
|
Corrosion
|
None
|
|
Pliability
|
No cracking
|
|
Mold and mildew
|
No growth
|
|
Fire rating
|
Class A / Class 1
|
OTHERS:
Max width: 1.50m
Length: according to customer request
Bubble diameter: 6mm, 10mm, 12mm, 20mm, 25mm
Product Feature And Application Of The ALUMINUM BUBBLE FOIL
Production Details Of The ALUMINUM BUBBLE FOIL
